FEATURES & BENEFITS
- 2°C to 10°C temperature range
- Overall stainless steel 304 construction
- Individual refrigeration system for each chamber
- Separate doors and handles for each chamber
- Stainless steel 304 trolley w/ roller wheels
- Microprocessor based temperature controller
- Audio and visual safety alarms
TECHNICAL SPECIFICATIONS
Temperature range | 2°C to 10°C |
Temperature controller |
|
Display precision | 0.1°C |
Temperature sensor | Platinum resistance temperature sensor |
Overall construction | Stainless steel 304 |
Insulation | PUF |
Trolley |
|
Doors |
|
Air circulation | Axial fan |
Illumination | LED light |
Alarms | Audio / visual alarms |
Power supply | 220 Volts 50Hz |
Optional |
|
STANDARD SIZES / DIMENSIONS
MODEL | BODIES | COMPRESSOR UNITS | EXTERNAL DIMENSIONS |
---|---|---|---|
MR1 | 1 | 1 | 2520*820*620 mm |
MR2 | 2 | 2 | 2520*850*1320 mm |
MR3 | 3 | 3 | 2520*850*1850 mm |
MR4 | 4 | 4 | 2520*1580*1300 mm |
MR6 | 6 | 6 | 2520*1580*1850 mm |
MR8 | 8 | 8 | 2520*1580*2200 mm |
Demo Video Single body
Mortuary Chamber -2Mortuary demo video
Freezer Mortuary cabinet Demo video
Six Mortuary chamber
